409L Grade Stainless Steel Plate with Corrosion Resistance and Customizable Dimensions for Industrial Applications
পণ্যের বিবরণ
| প্রস্থ | 1000mm/1219mm/1240mm/1500mm | পুরুত্ব | কোল্ড রোলড: 0.3 ~ 3.0 মিমি, হট রোলড: 3 মিমি ~ 100 মিমি |
|---|---|---|---|
| সারফেস ফিনিশ | N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, মিরর | গ্রেড | 200/300/400/500/600/700/800/900 সিরিজ/ডুপ্লেক্স স্টেইনলেস স্টিল |
| ইউএনএস | N08904 | এএসটিএম | 904L |
| এন | 1.4539 | JIS | SUS347 |
| কার্বন সামগ্রী | ≤0.03% | ম্যাঙ্গানিজ সামগ্রী | ≤2.0% |
| ফসফরাস সামগ্রী | ≤0.03% | সালফার সামগ্রী | ≤0.02% |
| সিলিকন সামগ্রী | ≤0.80% | ক্রোমিয়াম সামগ্রী | 21.0-23.0% |
| নিকেল সামগ্রী | 23.0-25.0% | ||
| বিশেষভাবে তুলে ধরা | 409L Grade Stainless Steel Plate,Corrosion Resistant Stainless Steel Plate,Customizable Dimensions Stainless Steel Sheet |
||
পণ্যের বর্ণনা
409L Stainless Steel Plate
Premium Stainless Steel Plates
Engineered for durability and performance, our stainless steel plates offer superior corrosion resistance and mechanical strength. Available in a wide range of grades and customizable dimensions to meet the stringent demands of modern industrial applications.
- Exceptional Corrosion Resistance
- High Strength-to-Weight Ratio
- Durable and Long-Lasting
- Versatile Application Suitability
- Customizable to Your Specifications
Ideal for: Construction, Manufacturing, Chemical Processing, Automotive, and more.
Product Specifications
| Brand | N/A |
| Origin | N/A |
| Material | Stainless Steel |
| Grade | 200, 300, 400 Series (and more) |
| Width | 1000mm - 2000mm |
| Thickness | Customizable |
| Standards | JIS, AISI, ASTM, GB, DIN, EN |
| Tolerance | ±1% |
| Packaging | Industry standard or custom |
Detailed Technical Specifications
Dimensions & Physical Properties
| Product Name | Width | Thickness | Length |
|---|---|---|---|
| Stainless Steel Plate | 1000mm/1219mm/1240mm/1500mm or as customer's requirements | Cold rolled: 0.3~3.0mm Hot rolled: 3mm~100mm |
As customer's request |
| Surface Finish | Grade | Standards | Certifications |
|---|---|---|---|
| N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, Mirror, etc. | 200/300/400/500/600/700/800/900 series/duplex stainless steel | AISI ASTM JIS SUS DIN GB | ISO 9001 |
Grade Specifications & Chemical Composition
| Payment Terms | Delivery Time | UNS | ASTM |
|---|---|---|---|
| T/T, L/C | Up to order quantity | S30100 | 301 |
| T/T, L/C | Up to order quantity | S30400 | 304 |
| T/T, L/C | Up to order quantity | S30403 | 304L |
| T/T, L/C | Up to order quantity | S30908 | 309S |
| T/T, L/C | Up to order quantity | S31008 | 310S |
| T/T, L/C | Up to order quantity | S31600 | 316 |
| T/T, L/C | Up to order quantity | S31603 | 316L |
| T/T, L/C | Up to order quantity | S31703 | 317L |
| T/T, L/C | Up to order quantity | S32100 | 321 |
| T/T, L/C | Up to order quantity | S34700 | 347 |
| T/T, L/C | Up to order quantity | S32750 | SAD2507 |
| T/T, L/C | Up to order quantity | S31803 | SAF2205 |
| T/T, L/C | Up to order quantity | N08904 | 904L |
| EN | JIS | C% | Mn% | P% | S% | Si% | Cr% | Ni% | Mo% |
|---|---|---|---|---|---|---|---|---|---|
| 1.4319 | SUS301 | ≤0.15 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.00 | 16.0-18.0 | 6.0-8.0 | - |
| 1.4301 | SUS304 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-10.5 | - |
| 1.4306 | SUS304L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-12.0 | - |
| 1.4833 | SUS309S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 22.0-24.0 | 12.0-15.0 | - |
| 1.4845 | SUS310S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.50 | 24.0-26.0 | 19.0-22.0 | - |
| 1.4401 | SUS316 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| 1.4404 | SUS316L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| 1.4438 | SUS317L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 |
| 1.4541 | SUS321 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-12.0 | - |
| 1.4550 | SUS347 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-13.0 | - |
| 1.4410 | N/A | ≤0.03 | ≤1.2 | ≤0.035 | ≤0.02 | ≤0.80 | 24.0-26.0 | 6.0-8.0 | 3.0-5.0 |
| 1.4462 | N/A | ≤0.03 | ≤2.0 | ≤0.03 | ≤0.02 | ≤1.00 | 21.0-23.0 | 4.0-6.5 | 2.5-3.5 |
| 1.4539 | N/A | ≤0.03 | ≤2.0 | ≤0.035 | ≤0.03 | ≤1.00 | 18.0-20.0 | 23.0-25.0 | 3.0-4.0 |
